| Item | Specification |
| LCD Brand Name | Hannstar |
| Display Size | 9.7 inch |
| Model | TPV097HAH30PTL35 |
| Aspect Ratio | 4:3 (H:V) |
| Resolution | 1024(H) x 768 (V) |
| Active Area | 196.608(H) x 147.456(V)mm |
| Pixel Pitch | 0.192(H) x 0.192(V)mm |
| Outline Dimension | 210.21(H) x164.25(V) x 3.0(D)mm |
| Support color | 16.7M |
| Color Gamut | 50% NTSC |
| Display mode | Normally white(wide angle viewing) |
| View angle | L/R/U/D 70/80/80/80(3:00 o'clock) |
| Brightness | 350 cd/㎡（Support customization） |
| Contrast Ratio | 500：1 |
| Interface | LVDS , 30 pins Connector |
| Backlight | 30k hours, with LED driver |
| Operating temp. | -20℃ ~ +70℃ |
| Storage temp. | -30℃ ~ +80℃ |
