Current Products-Specification Book Download
HSD104IXN1-L30
-
brand: TOPVIEW（ Tuopu)
model:
Specifications: 1024 ×768
- Consultation hotline:Mr. Li (Jacky)：139 2362 5299 Mr. Ming (Mike)：139 2387 9327 Mr. Li (Leo)： 139 1709 9753
-
Product details
| Item | Specification |
| LCD Brand | Hannstar |
| Model | HSD104IXN1-L30 |
| Display Size | 10.4 inch |
| Aspect Ratio | 4:3 (H:V) |
| Resolution | 1024(H)x768 (V) |
| Active Area | 211.2(H) x 158.4(V)mm |
| Pixel Pitch | 0.20625(H) x 0.20625(V)mm |
| Outline Dimension | 236(H) x1734.3(V) x 7.4(D)mm |
| Support color | 16.2M |
| NTSC | 70% |
| Display mode | Normally black(IPS) |
| View angle | L/R/U/D 85/85/85/85 |
| Brightness | 800 cd/㎡ |
| Contrast Ratio | 900：1 |
| Interface | LVDS(6/8-bit) , 30 pins Connector |
| Backlight | 30k hours, with LED driver |
| Operating temp. | -20℃ ~ +70℃ |
| Storage temp. | -30℃ ~ +80℃ |
-
Specification book download
